Playing the AM/FM Radio

Honda Pilot / Honda Pilot 2009-2023 Owner's Manual / Features / Audio System Basic Operation / Playing the AM/FM Radio

Auto Select

Auto Select

Use the auto select feature to scan both bands and store the strongest station in each preset.

1. Press the SETUP button.

2. Rotate then press   . to select Auto Select, then press 3. Select ON, then press   .  .

3. Select ON, then press To turn off auto select, select OFF, then press  .

To turn off auto select, select OFF, then press set. . This restores the presets you originally set.

Playing the AM/FM Radio

The ST indicator appears on the display indicating stereo FM broadcasts. Stereo reproduction in AM is not available. Switching the Audio Mode Press the MODE button on the steering wheel.

You can store six AM stations and twelve FM stations into the preset button memory. FM1 and FM2 let you store six stations each. Auto Select function scans and stores up to six AM stations and twelve FM stations with a strong signal into the preset button memory. If you do not like the stations auto select has stored, you can manually store your preferred frequencies.

Radio Data System (RDS)

Provides text data information related to your selected RDS capable FM station.


Press the TITLE button while listening to an RDS capable station. RDS INFO ON appears, and the station name is displayed.

To find an RDS station from your selected program category

1. Press the FOLDER bar or the CATEGORY bar to display and select an RDS category.

2. Use SKIP or SCAN to select an RDS station.

Playing the XM® Radio
